CE marking
UK marking
CMim marking
APPlus certificate
Free of halogens

Ref. 100888TP

Sealed connection box 310 x 240 x 125 mm with cones. Grey colour and transparent cover.

Sealed connection box 310 x 240 x 125 mm with cones. Grey colour and transparent cover.IP55. IK08. Plastic threaded screw closure. With 4 cones for tube Ø 32 mm, 2 cones for tube Ø 40 mm and 6 cones for tube Ø 50 mm.


Common applications: Industrial environments (factories, warehouses, etc.)

Add to zip Added to zip
Add to my downloads
Added to my downloads
More info
Add to zip Added to zip
Add to my downloads
Added to my downloads
More info

Complementary products

Features

Enclosure type Connection and derivation
Installation method Surface
Use Domestic / Tertiary
Location type Exterior and interior
Dimensions outside (mm) (width x height x depth) 320x251x134
Dimensions inside (mm) (Width x Height x Depth) 310x240x125
Case material Insulation
Case color Grey (RAL7035)
Cap color Grey (RAL 7035)
Ticket type With cones
No. of inlets and size (mm) 4xØ32, 2xØ40, 6xØ50
Fixation System (For surface) Exterior
Sealable Yes
Lid closure system Plastic screw
Possibility of mounting strips Yes (not included)
Possibility of mounting plate Yes (not included)
Possibility of mounting DIN rail Yes (not included)
Captive screw Yes
Captive Lid Yes
Valid for photovoltaic installations Yes
sketch

Technical data and regulation

Technical data

Protection Degree (IP) IP55
Protection Degree (IK) IK08
Impact shock resistance Strong
Insulation class Class II
Fire resistance (GWEPT) 650 ºC
Heat resistance (Ball pressure) 70 ºC
Ambient operating temperature -5 ºC ; +60 ºC
Work stress <1000 Vac ; 1500 Vdc
UV resistance Yes
Free of halogens Yes

Regulations

CE marking Yes
UK marking Yes
CMim marking Yes
According to Regulations UNE/EN UNE-EN 60670-1:2022
UNE- EN 60670-22:2007
According to REBT Yes
APPlus certificate Yes
According to European Directive 2014/35 / EU. Low voltage directive Yes

Sustainability

According to European Directive 2011/65/UE (RoHS) The Directive 2011/65/EU (RoHS II) is not applicable as it does not correspond to the definition of Electrical and Electronical Equipment (EEE) as per article 3.1
According to European Directive 2012/19/UE (RAEE2) Not applicable because it does not meet the definition of Electrical and Electronic Equipment (EEE) as described in Article 3.1(a) of Directive 2012/19/EU (WEEE II).

Logistics and packaging

Unit EAN code 8423220073067
EAN code container 8423220073067
EAN code packaging 18423220073064
Units packaging 1
Units carton 10
Pallet Units 150
Packaging Measures cm 59,5x59,5x39,5
Unit weight (g) 1200
Container Weight (Kg) 1,21
Packaging Weight (Kg) 13,27
Tariff code 85381000
