In photovoltaic solar installations—particularly those with multiple strings of panels—the string combiner box is a crucial component that ensures the safety, efficiency, and monitoring of the system. Often overlooked during the early design phases, this panel plays a vital role in managing direct current (DC) protection and control, acting as the connection point between solar modules and the inverter.
This article explains what a string combiner box is, its core components, and why proper selection and assembly are essential for the optimal performance of any solar power system.
What Is a String Combiner Box?
Also known as a string control panel, a string combiner box is a device that connects, protects, and monitors several strings of solar panels operating in direct current, before the energy is sent to the inverter.
Its main functions include:
- Isolating each string individually
- Providing protection against overcurrents and short circuits
- Detecting performance issues in specific strings
- Facilitating maintenance and overall system supervision
String combiner boxes are particularly important in medium to large-scale installations such as solar farms, industrial rooftops, and commercial photovoltaic plants.
Main Components of a String Combiner Box
The quality, reliability, and functionality of a string combiner box depend on the correct selection and installation of its internal components. Below are the essential elements of any well-designed system.
DC Disconnect Switches
These allow for manual disconnection of individual strings or groups of strings, enabling safe maintenance or component replacement without shutting down the entire system.
Key features:
- Designed specifically for DC and capable of extinguishing electrical arcs
- Available for 600 V, 1000 V, or 1500 V DC systems
- Required by safety standards to allow secure isolation
String Fuses or Circuit Breakers
Each string must be individually protected to prevent faults from affecting the whole system or damaging the inverter.
Options include:
- gPV fuses, specifically made for photovoltaic applications
- DC miniature circuit breakers (MCBs), which can be reset manually after tripping
These should be housed in labelled, secure, and accessible holders.
Surge Protection Devices (SPDs)
Transient overvoltages can result from lightning strikes, switching operations, or electromagnetic induction. SPDs protect the system against these voltage spikes.
Important features:
- Designed for use in DC systems
- Equipped with visual and/or remote status indicators
- Some models include signalling contacts for integration with control systems
String Monitoring Devices
These components measure current and voltage from each string individually, helping identify imbalances and optimising maintenance routines.
Common technologies:
- Precision shunts or Hall-effect sensors
- Voltage readers for each input or group of inputs
- Integration with inverters or data loggers for real-time data
They are ideal for early fault detection caused by shading, dirt, or module degradation.
Data Loggers or Controllers
These devices collect and transmit data to the energy management system or SCADA platform.
Key functions:
- Monitoring current, voltage, temperature, SPD status, and more
- Communication via RS-485, Ethernet, 4G, or other interfaces
- Providing historical analysis, alarm management, and remote diagnostics
Terminal Blocks and Connection Strips
Used to neatly organise the connection of input and output cables while ensuring reliable current distribution.
Important requirements:
- Compatible with high DC currents
- Built from materials resistant to corrosion and high temperatures
- Secure connections with durable labelling
Enclosures and Boxes
The enclosure protects all internal components of the combiner box against external environmental conditions.
Key characteristics:
- Minimum IP65 protection rating; IP66 is recommended for outdoor installations
- IK08 mechanical impact resistance or higher
- Made from materials resistant to UV radiation and chemicals
- Sufficient internal space for natural or forced ventilation
Why Each Component Matters for Safety and Performance
Incorrect sizing or the absence of key components can lead to serious issues such as:
- Fire hazards caused by undetected overloads
- Energy production losses due to unmonitored faults
- Difficulties in performing system diagnostics or maintenance
- Non-compliance with legal and regulatory standards
Regulatory Standards and Assembly Best Practices
To ensure safety and compatibility, string combiner boxes must comply with international standards such as:
- IEC 60364-7-712 -- Requirements for photovoltaic installations
- UNE-EN IEC 61439-2 -- Low-voltage switchgear assemblies
- UNE-HD 60364 -- General rules for electrical installations
Best practices include:
- Avoiding exposed, unlabelled, or loosely connected wiring
- Using only components certified for direct current
- Ensuring designs allow space and accessibility for future upgrades
- Preventing overheating by incorporating appropriate ventilation
The Role of the Combiner Box in Solar System Efficiency
The string combiner box plays a pivotal role in safeguarding the performance and reliability of photovoltaic installations. It is not merely a connection point but a central hub for protection, monitoring, and safe disconnection. Proper selection of components—including DC fuses, circuit breakers, SPDs, and connection terminals—must be based on installation conditions, current levels, and regulatory demands.
The enclosure is equally critical, offering insulation, mechanical resistance, and protection from dust, water, and UV exposure. For further technical insights, we recommend reading our articles on IP protection, IK impact resistance, and UV durability ratings.
At Solera, we are dedicated to supporting engineers and installers with certified, durable solutions for solar energy systems. For streamlined planning and setup, explore our online String Combiner Box Configurator.
Design smarter. Protect better. Trust in Solera's experience and know-how.
