Ref. AP1020NG
Flat corner 10x20. Graphite.
Flat angle for 10x20 mm mini-trunking. Graphite finish ensures clean and aesthetic joints in internal corners of electrical installations.
Add to my downloads
Added to my downloads
Add to my downloads
Added to my downloads
Complementary products
Features
Installation method Surface
Use Domestic / Tertiary
Location type Inside
Common applications Indoor domestic / tertiary environment (Interior of home, offices, shops, etc.)
Dimensions (Height x Width - mm) 10 x 20
Composition Loose lid
Technical data and regulation
Technical data
Fire resistance (GWEPT) 850 ºC
Work temperature Code: 321
Free of halogens Yes
Regulations
CE marking Yes
UK marking Yes
CMim marking Yes
According to Regulations UNE/EN UNE-EN 50085-1:2006
In accordance with the Low Voltage Electrotechnical Regulations (REBT) Yes
According to European Directive 2014/35 / EU. Low voltage directive Yes
Sustainability
According to European Directive 2011/65/UE (RoHS) The Directive 2011/65/EU (RoHS II) is not applicable as it does not correspond to the definition of Electrical and Electronical Equipment (EEE) as per article 3.1
According to European Directive 2012/19/UE (RAEE2) Not applicable because it does not meet the definition of Electrical and Electronic Equipment (EEE) as described in Article 3.1(a) of Directive 2012/19/EU (WEEE II).
Logistics and packaging
Unit EAN code 8423220281042
EAN code container 8423220280977
EAN code packaging 18423220280974
Units packaging 40
Units carton 1200
Pallet Units 58800
Packaging Measurements cm 9x7x19
Packaging Measures cm 37,5x30x20
Container Weight (Kg) 0,046
Packaging Weight (Kg) 1,712
Tariff code 85366990.99
